Tricolor Abstraction to build concurrent Garbage Collectors
The Mark and Sweep garbage collection algorithm is a simple DFS traversal with two phases - Mark and Sweep. In the mark phase, it marks all the objects that are reachable from the root, and the Sweep phase clears off all the unreachable ones.
This crude algorithm is slow and requires a program pause which means everything stops when the GC is cleaning up. This affects the performance and throughput of the program.
So, can we write a GC that runs concurrently with the program and does not need to always stop the world?
The foundation of concurrent Garbage Collector is based on a concept called Tricolour Abstraction which was developed by Dijkstra and Lamport, known for their work on core algorithms and distributed systems.
States of an object
While tracing the objects across the heap we can see that each object can be in one of the 3 states: unprocessed, processing, and processed; and this becomes our three colors
White: unprocessed objects Grey: visited but whose children are yet to be visited Black: done processing
The garbage collection flow
Every node starts white. Once we see an object we color it Grey and once we are done visiting its children we mark it Black. This way we have 3 sets of objects: white, great, and black, and the objects move from white to grey and from grey to black.
A key thing to note here is that we will never have an object that moves directly from white to black; i.e. there will never be an edge that connects one black and one white node.
How does Tricoloration make it better?
Because a black node is never connected to a white node, we ensure correctness i.e. a live object will never be cleaned up.
Our GC flow can now be simplified as
pick the object from the grey set
color all the children of the node grey
move the grey object to the black
repeat the flow until the grey set is empty. Once done, we can just visit the white set, which now contains all the unreachable objects, and clean them up.
Speedup
Now that we segregated the objects into sets we can ensure a quick cleanup by putting more threads at work on the grey set. It is hard to make a crude DFS concurrent and structuring it as sets make implementation much simpler.
We make our system reactive by keeping an eye on the grey set and triggering GC as soon as it hits some threshold.
This method of garbage collection is called "on-the-fly" which runs concurrently with the program and mutates the color of the objects as part of program execution and does not wait for a separate GC cycle. This reduces the load on GC and minimizes the pause.
Here's the video of my explaining this in-depth 👇 do check it out
A basic Mark-and-Sweep garbage collection algorithm operates in Stop-the-World mode, which means the program execution pauses while the GC runs. So, can we write a GC that runs concurrently with the program and does not need to always stop the world?
In this video, we take a look into something foundational called the Tricolour Invariant that enables us to build concurrent garbage collectors with low pause times. The concept we discuss is something that was contributed by Dijkstra, famously known for his Shortest Path algorithm.
Outline:
00:00 Agenda
03:06 Recap of Mark and Sweep Garbage Collection
03:56 States of an object during GC
06:04 Tricolour Abstraction
09:07 How does Tricolor Abstraction make things better?
12:46 The Garbage Collection Flow with the Coloured Sets
15:06 Why did we do this at all?
