Building a Robust Payments Service
Idempotence is executing the same action multiple times, but the result is as if the operation was applied just once.
Example: Double tapping a post multiple times on Instagram does not increase the like count. It just increases the first time and by 1.
Idempotence becomes extremely critical when money is involved. If A wants to transfer money to B, the transfer should happen just once. If due for any reason, the payment is implicitly retried, the funds will be deducted twice, which is unacceptable.
Why would a transaction repeat?
Before we talk about idempotence, it is important to understand why it would repeat in the first place.
Consider a situation where the payments service initiated a payment with a Payment Gateway, the money got deducted, but the payments service did not get the response. This would make the Payments service retry the API call, which would lead to a double deduction.
Implementing idempotence
Check and Update: Weave everything with a single ID.
The idea is to retry only after checking if the payment is processed or not. But how do we do this? The implementation is pretty simple- a global payment ID that weaves all the services and parties together.
The flow is:
Payments service calls the PG and generates a unique Payment ID
Payments service passes this ID to the end-user and all involved services
Payments service initiates the payment with Payment Gateway with this ID specifying the transfer between A and B
If there are any failures, the Payment service retries and in that request specifies the Payment ID
Using the payment ID, the payment gateway checks if the transfer was indeed done or not and would transfer only when it was not done
Although we talked about the Payments service here, this approach of implementing idempotence is pretty common across all the use cases. The core idea is to have a single ID (acting as the Idempotence Key) weaving all the involved services and parties together.
Here's the video of my explaining this in-depth 👇 do check it out
Idempotence is an extremely critical property that we must consider while implementing an API or designing a microservice. The situation becomes even more critical when the money is involved - ensuring no matter how many times the user or internal service retries, the amount is transferred just once between the two users in one transaction.
This video looks at idempotence, why there is even a need for it, and, more importantly, one common implementation approach commonly observed in payments services.
Outline:
00:00 What is Idempotence?
02:32 Examples where Idempotence is relevant
04:06 Why do we even need to retry?
07:18 Implementation Approach 1: Do not retry
09:45 Implementation Approach 1: Check and Update
