Implementing Hash Maps with Hash Tables
A map, when implemented with Hash Tables, is called a Hash Map; and just like a regular map it supports operations like put, get, and iterate.
Key Implementation Details
Hash Maps are required to store the application keys of any type, but the Hash Table understands only integers. We first pass the application keys through a hash function to map it to a 32-bit integer, and then the usual Hash Table operation takes over.
Given that the application key to hash key is a frequent operation, we would keep it handy by storing it alongside the application key. This helps us save repeated computations.
While looking up a key in the hash map, we first reach the slot, and then compare if the key present there is really the key we are looking for, as we cannot just rely on the equality of the hash keys. The Hash Map, hence, accepts a key comparator function.
With Chained Hash Tables
Each node of the linked list in the chained hash table has the following structure
struct node {
int32 hash_key;
void *key;
void *value;
struct node *next;
}
void * key and void * value allows us to hold a key and a value of any type, while int32 hash_key enables us to hold a pre-computed hash.
At the Hash Table level, we hold
the array of linked list
size of the array
number of keys
key comparator function
Instead of having a contains function, we have a lookup function that returns the value for the matching key, and NULL if the key does not exist. Thus, the lookup function doubles as a contains function.
When duplicate keys are inserted, we can do one of the following
do not insert at all
delete the old key and re-insert it again, bringing it to the head of the list, making it quicker to reach
With Hash Tables having open addressing
Each slot of the hash table has the following structure
struct node {
int32 hash_key;
void *key;
void *value;
bool is_empty;
bool is_deleted;
}
void *key and void *value allows us to hold a key and a value of any type, while int32 hash_key enables us to hold a pre-computed hash, saving a lot of runtime computations. is_empty tells us if the slot is empty, while is_deleted represents a soft deleted slot.
At the Hash Table level, we hold
the array of linked list
size of the array
number of active keys
number of used slots
key comparator function
Here the load factor will be computed as number of used slots/size of the array because the soft deleted keys also affect the performance of the hash table.
During insert, lookup, and delete when we find the matching hash, and explicitly compare the application keys, as multiple keys can hash to the same location, and we cannot rely on just hash key equivalence.
