How Airbnb designed and scaled its central authorization system - Himeji
Building a central, robust, extensible and highly available authorization service is no joke
and @Airbnb does it beautifully
here's a thread about its architecture and key design decisions... 🧵👇
What is authorization?
It is all about managing fine-grained control over different entities, for example:
can user A edit comment C?
can user B access hotels in region R?
can user C read a file in folder F shared with group G?
why do we need a service for this?
Why a central service?
If each microservice handles its own authorization, then there would be
duplication of auth logic
inter-service calls to check for auth
hence, it is beneficial to create a central auth service. Let's see how it is modeled.
Auth model
Principal: user or service that needs to be tested
Entity: on which we are checking the access
Relation: between entity and principal
can user A edit comment C?
A - is the principal, C - is the entity, and edit - is the relation
The tuple is represented and (optionally stored) in the database as
<entity> # <relation> @ <principal>
if user A has owner privileges on comment C, it will be represented (and optionally stored) as
C # OWNER @ A
Storing one entry for each entity and relation will make the data explode, For example:
if A owns a comment C, then he/she can read and write to it as well. This would make us have 3 entries in the database
C # READ @ A
C # WRITE @ A
C # OWNER @ A
hence...
we need a way to define relations between relations and entities to reduce the size of the data.
A simple YAML-based config would look like this
``` LISTING:
# WRITE: union: - # WRITE - # OWNER
# READ: union: - # READ - # WRITE ```
The above configuration implies,
WRITE relation is a union of WRITE and OWNER
READ relation is a union of READ and WRITE
Anyone with the write and owner relation can write and anyone with read and write (and transitively owner) relations can read the listing on Airbnb.
To check if user A can read listing L, we hit
check (listing:L, READ, user:A)
It evaluates as
LISTING:L # READ @ user:A
LISTING:L # WRITE @ user:A
LISTING:L # OWNER @ user:A
because of union
, if anyone of these exists in DB, check
evaluates to True.
Architecture
Himeji (authorization) service is consist of 3 layers
Data Layer
Caching Layer
Orchestration Layer
Let's take a detailed look at each in detail.
Data Layer
The data layer of the Himeji service consists of
persistent relational database
data is logically shared within the same instance
any mutation in the data is read through CDC, streamed through Kafka, and used in invalidating the cache
Caching Layer
The caching layer of the Himeji service is super-critical for performance as it ensures low response time at scale.
ensures a 98% hit ratio
cache cluster is sharded
consistent hashing determines the data ownership across the cluster
Orchestration Layer
The orchestration layer is used by clients and internal jobs to interact with the service. The layer
forwards reads to caching
forwards the writes to the data layer
computes response as per the config
This design is taken from @Airbnb's Engineering Blog and it is linked in the description of the video attached.
