API Composition Pattern in Microservices
Say, we have 3 microservices - Order, Payments, and Logistics - and to get the order details we need data from all of them, merge it, and then respond to the client. A common pattern to achieve this is API Composition.
API Composition
It is a high-level pattern to query microservices. It puts a composer right in the middle abstracting out the microservices.
With the composer sitting in between, the request from the client first hits the composer, and the composer then talks to the relevant services to get the response. It then merges the responses before sending them to the client.
Implementing API Composition
Instead of building it from scratch, we can use tools that specialize in achieving this - ex: API Gateways like KrakenD, Kong, and AWS API Gateway.
Improving user's experience using composer
An API Composer not only helps in making the backend simpler, but it also helps in gaining a good UX.
If we do not have an API composer, the client (browser/app) would have to make multiple API calls to microservices to get the information and render the interface. The multiple calls would require multiple round trips of the data increasing the latency and will also eat up the user's data.
By having an API composer sitting in between the client would only need to make one API call and the fan-out happening at composer will be within the infra. This would reduce the latency for clients and improve the UX.
Branch Composition
For a complex usecase, it is quite possible that a downstream service may use another composer to reach out to another set of services to get things done. A dependency like this would create a multi-level API composition also called Branch composition.
This would create a hierarchical dependency between services solved through multiple API composers and it is a common pattern observed in complex e-commerce platforms.
Advantages of using API Composition
Simple to implement
Client has a single point to interact
Hides the implementation complexities
Security and Limiting applied only to the composer
Can cover the "bad" design decisions with a shiny new interface
Hides legacy system allowing us to gradually move out of it
Disadvantages of using API Composition
If the dataset we fetch from microservices is large, it would make the composer in-efficient
Overall availability is challenged as the number of services increase
Having a transactional data consistency is difficult
Composer needs to be managed and maintained
Composer may become a bottleneck at scale
Here's the video of my explaining this in-depth 👇 do check it out
Say, we have very happily created 6/7 microservices and everything is going well. Now for a new usecase that is introduced in the product, we have to talk to not one but 3 services together to compile a response. So, what is a good way of implementing and supporting this kind of request? A high-level pattern that helps us do it is called API Composition.
In this video, let's in-depth talk about this super simple pattern to query Microservices, see what it is, how to implement it, understand how it not only helps in improving end user experience, and conclude by going through the advantages and disadvantages of adopting it.
Outline:
00:00 Agenda
02:54 Introducing API Composition
04:53 Implementing API Composition using API Gateway
06:44 Sequential vs Parallel Invocation
09:21 Improving end-user experience using API Composition
12:43 Branch or Multi-level API Composition
14:03 Advantages of API Composition and Gateways
18:49 Disadvantages of API Composition and Gateways
